- Micro bolómetro VOx no refrigerado con resolución de 400×300
- Lente fija de 8/15/25/35/50 mm opcional
- Sensibilidad ≤40mK
- Admite monitoreo de temperatura y alarma de excepción
- Rango de detección de temperatura: -20 °C a 150 °C (-4 °F a 302 °F)
- Admite 3 tipos de reglas de medición de temperatura (punto, línea, área)
- Análisis inteligente: intrusión, cruce de una sola línea, cruce de doble línea, objeto izquierdo, objeto eliminado
- 17 paletas de colores
- Mejora deimagen DVE
- Soporta fuente de alimentación PoE
- IP66
Detalle de productos
|
Thermal Camera |
|||||
|
Detector Type |
Uncooled VOx Micro bolometer |
||||
|
Pixel Size |
17 um |
||||
|
Thermal Sensitivity (NETD) |
≤40 mK |
||||
|
Spectral Range |
8 ~ 14 um |
||||
|
Lens Type |
Fixed |
||||
|
Focus Control |
Manual Focus |
||||
|
Focal Length |
8 mm |
15 mm |
25 mm |
35 mm |
50 mm |
|
F No. |
F1.0 |
F1.0 |
F1.0 |
F1.0 |
F1.0 |
|
Angle of View |
H: 46°, V:35.3° |
H:25.5°, V:19.2° |
H:15.4°, V:11.6° |
H: 11°, V:9° |
H: 7.7°, V:5.8° |
|
Detection Distance Fire(1m*1m) |
235 m |
441 m |
735 m |
1029 m |
1471 m |
|
Detection Distance Man(1.8m*0.5m) |
235 m |
441 m |
735 m |
1029 m |
1471 m |
|
Detection Distance Vehicle(4m*1.5m) |
722 m |
1353 m |
2255 m |
3137 m |
4510 m |
|
Recognition Distance Fire(1m*1m) |
78 m |
147 m |
245 m |
343 m |
490 m |
|
Recognition Distance Man(1.8m*0.5m) |
59 m |
110 m |
184 m |
257 m |
368 m |
|
Recognition Distance Vehicle(4m*1.5m) |
180 m |
338 m |
564 m |
789 m |
1127 m |
|
Video and Audio |
|||||
|
Resolution |
Sensor is 400×300. Image can be scaled up to 704×576 |
||||
|
Frame Rate |
Main Stream: 704×576 @ 25/30fps, Sub Stream: CIF @ 25/30fps |
||||
|
Bit Rate Control |
CBR/VBR |
||||
|
Bit Rate |
100Kbps ~ 6Mbps |
||||
|
Region of Interest |
Off / On (8 Zone, Rectangle) |
||||
|
Digital Zoom |
16x |
||||
|
Mirror |
Support |
||||
|
Defog |
Support |
||||
|
Motion Detection |
Support |
||||
|
Privacy Masking |
Off / On (4 Area, Rectangle) |
||||
|
DVE Image Enhance |
Support |
||||
|
Image Setting |
Brightness/Sharpness/Contrast/Mirror/FFC/3D DNR |
||||
|
Color Palettes |
White-hot/Black-hot/Rainbow/Ironbow etc. up to 17 modes |
||||
|
Audio Compression |
G.711: 8kbps, RAW_PCM: 16kbps |
||||
|
Intelligence |
|||||
|
Intelligent Functions |
Motion detection, Disk alarm, I/O alarm, Temperature detection & alarm |
||||
|
IVS |
Perimeter, Single Virtual Fences, Double Virtual Fences, Object Left, Object Removed |
||||
|
Temperature Detection |
|
|
Temperature Detection |
Support 3 temperature measurement rule types (Spot, Line, Area) |
|
Temperature Alarm |
Over temperature alarm, Temperature difference alarm |
|
Accuracy |
±2℃ / ±2% |
|
Response Time |
≤ 30ms |
|
Theory of temperature measurement range |
-40°C ~ 150°C (-40°F ~ 302°F) |
|
Temperature display mode |
Temperature target ＞5℃, Display absolute temperature value, Temperature target ≤5℃, Display relative temperature value (temperature difference DEV = highest value - average) |
|
Network |
|
|
Ethernet |
RJ-45 (10/100Base-T) |
|
Protocols |
IPv4/IPv6 ,HTTP,RTSP/RTP/RTCP, TCP/UDP, DHCP, DNS, PPPOE, SMTP, 802.1x |
|
Interoperability |
ONVIF, CGI, SDK |
|
Streaming Method |
Unicast |
|
Max. User Access |
10 Users |
|
Edge Storage |
Local PC for instant recording, Micro SD card 128GB |
|
Web Viewer |
<IE11, Chrome, Firefox, Microsoft Edge |
|
Web Language |
English, Chinese, Polish, Italian, Portuguese, Spanish. Russian, French, Czech, Hungarian |
|
Interface |
|
|
Ethernet |
1 Ethernet (10/100 Base-T) RJ-45 Connector |
|
Audio Interface |
1ch Audio In,1ch Audio Out |
|
Alarm |
2ch Alarm In,2ch Alarm Out |
|
RS485 |
Support |
|
BNC Output |
Support |
|
Reset Button |
Support |
|
General |
|
|
Power Supply |
DC12V/POE (IEEE 802.3af) |
|
Power Consumption |
Max 5 W |
|
Working Temperature |
-40°C ~ 60°C (-40°F ~ 140°F) |
|
Storage Conditions |
0~ 90% RH |
|
Certifications |
CE/FCC |
|
Ingress Protection |
IP66 |
|
Casing |
Metal |
|
Dimensions |
φ110 × 388 mm (φ4.33 × 15.28 inch) |
|
Net Weight |
1.8 kg (4.97 lb) with 15mm lens |
